650-670w Efficiency TOPCON Solar Cell System Module With Wide Temperature Range Sturdy Frame
  • 650-670w Efficiency TOPCON Solar Cell System Module With Wide Temperature Range Sturdy Frame
  • 650-670w Efficiency TOPCON Solar Cell System Module With Wide Temperature Range Sturdy Frame

650-670w Efficiency TOPCON Solar Cell System Module With Wide Temperature Range Sturdy Frame

Power: 650w
Operating Voltage (Vmpp/V): 37.6
Operating Current (Impp/A): 17.29
Efficiency: 20.9%
Dimension: 2384x1303x30mm
Weight: 38.5kg
Connector Type: MC4
Operating Temperature: -40°C To +85°C
Download

Product Details

Warranty::
25 Years
Frame Material::
Anodized Aluminum Alloy
Certifications::
TUV
Glass Type::
Tempered Glass
Cell Type::
Monocrystalline
Highlight::

mc4 topcon pv cell

,

tuv topcon pv cell

,

mc4 topcon solar cell

Place of Origin:
China
Brand Name:
SANGSOLAR
Certification:
CE/TUV/BSP/CSI
Model Number:
SANGSOLAR
Minimum Order Quantity:
Pallet
Price:
Negotiated
Packaging Details:
Carton on Pallet
Delivery Time:
10-30days
Payment Terms:
TT/LC/Alibabashop
Supply Ability:
20GW/Year
Highlight:

mc4 topcon pv cell

,

tuv topcon pv cell

,

mc4 topcon solar cell

Product Description

650-670w Efficiency TOPCON solar system module with Wide Temperature Range Sturdy Frame

Product Description:

With a TUV certification, you can be confident that the TOPCON Solar PV Module is a reliable and safe choice for your energy needs. The module is designed to withstand harsh weather conditions and is made with tempered glass, providing excellent durability and protection against environmental factors.

The TOPCON Solar Power Panels offer an impressive efficiency rating of 18.3%, ensuring that you get maximum power output from every module. This means that you can generate more energy from your solar system, saving you money on your energy bills and reducing your carbon footprint.

When you choose the TOPCON Solar Module, you can rest assured that you are investing in a high-quality product that is backed by a 25-year warranty. This warranty covers defects in materials and workmanship, giving you peace of mind knowing that your investment is protected.

Whether you are looking to install a solar power system for your home or business, the TOPCON Solar Module is an excellent choice. With its superior efficiency, durable design, and long warranty, this module is sure to provide you with reliable and cost-effective energy for many years to come.



Features:

GCL Delivers Reliable Performance Over Time

●World-class manufacturer of crystalline silicon photovoltaic modules

● Fully automatic facility and world-class technology

●Rigorous quality control to meet the highest standard:IS09001,ISO

14001 and IS045001

·Tested for harsh environments Isalt mist,ammonia corrosion and sand

blowing test:IEC 61701,IEC 62716,DIN EN 60068-2-68]

● Long term reliability tests

●2×100%EL inspection ensuring defect-free modules

Applications:

With an efficiency rate of 20.9%, the Sangsolar TOPCON Solar Module is the perfect choice for individuals or businesses looking to reduce their energy costs and carbon footprint. This TOPCON solar system module is also TUV certified, ensuring that it meets strict quality and safety standards.

The Sangsolar TOPCON Solar Module is easy to install and comes with MC4 connectors, making it compatible with most solar panel systems. It can be used in various applications, including residential, commercial, and industrial settings. Here are some scenarios where the Sangsolar TOPCON Solar Module can be beneficial:

  • Residential: Homeowners can install the TOPCON solar photovoltaic panel on their rooftops to generate electricity and save on energy bills. The panel's durability ensures that it can withstand harsh weather conditions, making it a reliable and long-lasting investment.
  • Commercial: Businesses can install the Sangsolar TOPCON Solar Module on their rooftops or carports to reduce their energy costs and improve their environmental sustainability. The panel's high efficiency makes it an excellent choice for businesses looking to maximize their energy savings.
  • Industrial: The Sangsolar TOPCON Solar Module can also be used in industrial settings to power machinery and equipment. Its durability and efficiency make it a practical and cost-effective alternative to traditional energy sources.

In conclusion, the Sangsolar TOPCON Solar Module is a reliable, efficient, and cost-effective solar photovoltaic panel that can be used in various applications. Its durability and TUV certification ensure that it meets strict quality and safety standards. Whether you're a homeowner, business owner, or industrial operator, the Sangsolar TOPCON Solar Module is an excellent investment for reducing energy costs and promoting environmental sustainability.

Electrical Specification(STC*)

Maximum Power PmaxlW 650 655 660 665 670
Maximum Power Voltage VmplV 37.6 37.8 38 38.2 38.4
Maximum Power Current lmol4l 17.29 17.33 17.37 17.41 17.45
Open Circuit Voltage VoclM 45.4 45.6 45.8 46 46.2
Short Circuit Current Isc[A] 18.21 18.26 18.31 18.36 18.41
Module Efficiency [%] 20.9 21.1 21.2 21.4 21.6
Power Output Tolerance [W] 0-+5

Electrical Specification(NMOT*)



Maximum Power Pmax (W) 491.8 495.6 499.4 503.1 506.9
Maximum Power Voltage Vmp(V) 35.08 35.26 35.45 35.64 35.82
Maximum Power Current Imp [A] 14.02 14.05 14.09 14.12 14.15
Open Circuit Voltage Yociv 42.77 42.96 43.14 43.33 43.52
Short Circuit Current lsc (A) 14.68 14.72 14.76 14.8 14.84



Mechanical Data



Number of Cells 132 Cells [6×22]
Dimensions of Module L*W*H (mm)

2384×1303×33mm [93.86×51.30×1.30 inches]

Weight [kg] 38.5 kg
Glass High transparencytempered glass 3.2 mm[0.13 inches]
Backsheet White
Frame Silver,anodized aluminium alloy
J-Box IP68 Rated
Cable 4.0mm²,Por trait:+400/-200mm length can be customized
Number of diodes 3
Wind/Snow Load 2400Pa/5400Pa*
Connector MC Compatible

Support and Services:

TOPCON Solar Module offers the following technical support and services:

- Technical consultation for system design and installation

- Troubleshooting and maintenance support

- Warranty and repair services

- Training for installers and contractors

- Performance data monitoring and analysis

- Customized solutions for unique project requirements



Packing and Shipping:

Product Packaging:

The TOPCON Solar Module product will be packaged in a sturdy cardboard box to ensure safe delivery. Each module will be individually wrapped with protective material to prevent any damage during shipping. The box will also contain installation instructions and a warranty card.

Shipping:

The TOPCON Solar Module product will be shipped via a trusted and reliable courier service to ensure timely and secure delivery to the customer. The shipping cost will be calculated based on the destination and weight of the package. Customers will receive a tracking number to monitor the progress of their shipment.



FAQ:

Q1: What is the brand name of the solar module?

A1: The brand name of the solar module is Sangsolar.

Q2: Where is the Sangsolar solar module manufactured?

A2: The Sangsolar solar module is manufactured in Beijing, China.

Q3: What is the power output of the Sangsolar solar module?

A3: The power output varies depending on the model of the solar module. Please refer to the product specifications for more information.

Q4: Can the Sangsolar solar module be used for residential purposes?

A4: Yes, the Sangsolar solar module is suitable for both residential and commercial applications.

Q5: Does the Sangsolar solar module come with a warranty?

A5: Yes, the Sangsolar solar module comes with a warranty. Please refer to the product warranty for more information.
