150kW Three-Phase Hybrid Solar Inverter with 240kW PV Input, 850V Battery Support, and Parallel Operation for Industrial Microgrids
  • 150kW Three-Phase Hybrid Solar Inverter with 240kW PV Input, 850V Battery Support, and Parallel Operation for Industrial Microgrids
  • 150kW Three-Phase Hybrid Solar Inverter with 240kW PV Input, 850V Battery Support, and Parallel Operation for Industrial Microgrids
  • 150kW Three-Phase Hybrid Solar Inverter with 240kW PV Input, 850V Battery Support, and Parallel Operation for Industrial Microgrids
  • 150kW Three-Phase Hybrid Solar Inverter with 240kW PV Input, 850V Battery Support, and Parallel Operation for Industrial Microgrids

150kW Three-Phase Hybrid Solar Inverter with 240kW PV Input, 850V Battery Support, and Parallel Operation for Industrial Microgrids

Max. Power (kVA): 165 KVA
Current (A): 416A (208V)/394A (220V)/361A (240V)
Frequency: 50/60 Hz (±5 Hz Adjustable)
Voltage Range: 420-850V
Dimensions (W×D×H): 1,200×800×2,050 Mm
Weight: 1,250-1,310 Kg
Highlight:

150kW hybrid solar inverter

,

three-phase inverter for industrial microgrids

,

solar inverter with 850V battery support

Download

Product Details

Brand Name:
sangsolar
Certification:
EN 62109-1/-2
Model Number:
MPS0150
Minimum Order Quantity:
Pallet
Price:
Negotiated
Packaging Details:
Carton on Pallet
Delivery Time:
10-30days
Payment Terms:
TT/LC/Alibabashop
Supply Ability:
2GW/Year
Highlight:

150kW hybrid solar inverter

,

three-phase inverter for industrial microgrids

,

solar inverter with 850V battery support

Product Description

150kW Industrial Hybrid Inverter - High-Capacity Power Solution for Demanding Microgrid Applications



Industrial-Grade Performance

This 150kW three-phase hybrid inverter delivers uninterrupted power for mission-critical industrial operations. Designed for harsh environments, it combines high-efficiency solar conversion, flexible battery integration, and intelligent grid management in one rugged package.



Key Differentiators from Lower-Capacity Models

  1. 50% More Power than 100kW models for heavy industrial loads

  2. Extra MPPT Trackers (up to 4) for complex solar arrays

  3. Enhanced Cooling System for continuous 24/7 operation



Technical Advantages

1. High-Capacity Energy Conversion

  • 150kW continuous output (165kVA peak)
    Handles simultaneous operation of heavy machinery (e.g., crushers, compressors)

  • <3% THDi clean power output
    Protects sensitive CNC equipment and medical devices

2. Intelligent Solar Harvesting

  • 2-4 independent MPPT trackers
    *Eliminates 18-22% power loss from panel mismatch vs. single-tracker systems*

  • 1,000V max PV input
    Reduces wiring costs by 30% through longer string designs

3. Industrial Battery Integration

  • 420-850V battery voltage range
    Directly connects to modern high-voltage lithium batteries

  • 240kW max charging power
    *2-hour recharge capability for shift-change operations*

4. Military-Grade Reliability

  • -30°C cold-start capability
    Proven in Arctic mining operations

  • IP20 protected components
    Withstands dusty quarry/mine environments

Technical Specifications

(Refer to Section 2 for complete specifications table)



Industrial Applications

● Heavy Industry

  • Mine dewatering pumps (24/7 operation)

  • Steel mill induction furnaces (high surge loads)

● Utility-Scale Storage

  • Peak shaving for factories

  • Solar farm battery integration

● Remote Infrastructure

  • Military base power

  • Off-grid oil rigs



FAQ

Q: How does this compare to 100kW models for data centers?
A: Provides 50% more capacity for N+1 redundancy, with extra MPPT trackers for diverse roof arrays.

Q: What battery communications are supported?
A: CAN 2.0B + RS485 for major lithium/LFP brands (Tesla, BYD, CATL compatible)

Q: Can it power entire factories during blackouts?
A: Yes, when paired with ≥500kWh storage - 8-10 hour runtime for typical assembly plants.



Installation Requirements

Structural Considerations

  • 1,300kg floor loading

  • 800mm clearance for airflow

Electrical Safety





  • 500A AC disconnect required

  • Surge protection mandatory for lightning zones

Category Specifications
AC Output (On-Grid)
Max. Power (kVA) 165 kVA
Rated Power (kW) 150 kW
Voltage Options 208V/220V/240V (Wye)
Current (A) 416A (208V)/394A (220V)/361A (240V)
Frequency 50/60 Hz (±5 Hz adjustable)
THDi <3%
Power Factor 0.8 leading/lagging (adjustable)
AC Output (Off-Grid)
THDu <1% (linear), <5% (nonlinear)
Overload Capacity 110% continuous
PV Input
Max. PV Voltage 1,000V
Max. PV Power 120/180/240 kW
MPPT Trackers 2/3/4
MPPT Voltage Range 250-850V
Battery
Voltage Range 420-850V
Max. Charging Power 120/180/240 kW
Physical Data
Dimensions (W×D×H) 1,200×800×2,050 mm
Weight 1,250-1,310 kg
Operating Temperature -30°C to 55°C
Protection Rating IP20
Noise Level <70 dB
Communication RS485, CAN, TCP/IP

  •
