30kW 480V High-Leg Delta Hybrid Inverter with Dual MPPT and Split-Phase Output for Industrial Applications
30kW 480V High-Leg Delta Hybrid Inverter with Dual MPPT and Split-Phase Output for Industrial Applications
  • 30kW 480V High-Leg Delta Hybrid Inverter with Dual MPPT and Split-Phase Output for Industrial Applications
  • 30kW 480V High-Leg Delta Hybrid Inverter with Dual MPPT and Split-Phase Output for Industrial Applications
  • 30kW 480V High-Leg Delta Hybrid Inverter with Dual MPPT and Split-Phase Output for Industrial Applications
  • 30kW 480V High-Leg Delta Hybrid Inverter with Dual MPPT and Split-Phase Output for Industrial Applications
  • 30kW 480V High-Leg Delta Hybrid Inverter with Dual MPPT and Split-Phase Output for Industrial Applications

30kW 480V High-Leg Delta Hybrid Inverter with Dual MPPT and Split-Phase Output for Industrial Applications

Max. Power (kVA): 33 KVA
Rated Power (kW): 30 KW
Voltage Range: 384-552V
Rated Current (A): 37A
Max. PV Voltage: 1,000V
Dimensions (W×D×H): 800×800×1,900 Mm
Highlight:

30kW hybrid inverter for industrial use

,

480V high-leg delta inverter with dual MPPT

,

split-phase output industrial inverter with warranty
Download

Product Details

Brand Name:
sangsolar
Certification:
EN 62109-1/-2
Model Number:
MPS0030-480S
Minimum Order Quantity:
Pallet
Price:
Negotiated
Packaging Details:
Carton on Pallet
Delivery Time:
10-30days
Payment Terms:
TT/LC/Alibabashop
Supply Ability:
2GW/Year
Highlight:

30kW hybrid inverter for industrial use

,

480V high-leg delta inverter with dual MPPT

,

split-phase output industrial inverter with warranty

Product Description

30kW 480V High-Leg Delta Hybrid Inverter - Industrial Power Solution

High-Performance Energy Conversion System

This 30kW hybrid inverter delivers industrial-grade three-phase power with split-phase flexibility, specifically designed for commercial and industrial facilities requiring 480V high-leg delta configuration. Featuring dual MPPT trackers and 250-850V battery integration, it achieves 98% peak efficiency while supporting parallel operation for scalable systems.



Key Differentiators

  1. 480V High-Leg Delta Output - Provides both three-phase 480V and split-phase 240V power

  2. Dual MPPT Design - Maximizes solar harvest in partial shading conditions

  3. Wide Battery Compatibility - Supports various lithium and lead-acid battery systems



Technical Advantages

1. Advanced Voltage Architecture

  • 480V high-leg delta with split-phase output
    *Technical note: Proprietary phase-balancing algorithm maintains <1% voltage imbalance while delivering both three-phase 480V and 240V single-phase power.*

  • 384-552V wide input range
    *Technical note: DSP-controlled voltage regulation with ±1% accuracy and <20ms response to grid disturbances.*

2. Precision Solar Harvesting

  • 1-2 MPPT trackers (36/72kW capacity)
    Technical note: Independent maximum power point tracking reduces mismatch losses by 30% in unevenly shaded arrays.

  • 1,000V DC input with 250-850V MPPT range
    *Technical note: Cold-start capability at 150V with 1,200V surge protection for harsh environments.*

3. Flexible Battery Integration

  • 250-850V battery voltage range
    Technical note: Integrated battery health monitoring tracks impedance changes (±2% accuracy) for predictive maintenance.

  • 72kW max charging power
    *Technical note: Adaptive 3-stage charging (bulk/absorption/float) with temperature compensation.*

4. Rugged Industrial Design

  • -30°C cold-start with 55°C continuous operation
    *Technical note: Military-grade components rated for 100,000+ hours MTBF in extreme conditions.*

  • IP20 enclosure
    Technical note: Corrosion-resistant coating on all external components for industrial environments.



Target Applications

● Industrial Facilities

  • Machine shops
    Technical note: Clean power (<3% THDi) ensures precision tool operation.

  • Manufacturing plants
    Technical note: Handles high surge loads during equipment startups.

● Commercial Buildings

  • Office complexes
    Technical note: Split-phase output for lighting and outlets.

  • Retail centers
    Technical note: Parallel operation for load sharing.

● Agricultural Operations

  • Irrigation systems
    Technical note: Withstands dusty environments and temperature extremes.



FAQ

Q: Can this inverter power both three-phase and single-phase equipment simultaneously?
*A: Yes, the high-leg delta configuration supplies both three-phase 480V and split-phase 240V without additional transformers.*

Q: What battery communications are supported?
*A: CAN 2.0B for Pylontech/BYD, RS485 for Tesla Powerwall, Modbus TCP for SCADA integration.*

Q: Is professional installation required?
A: Yes, due to the high-voltage components and specialized electrical configuration.



Installation Requirements

⚠ Electrical

  • 60A minimum disconnect

  • #6 AWG copper wiring for 37A continuous current

  • Separate neutral-ground bond

⚠ Environmental



  • 30cm clearance around ventilation ports

  • Dust filters in high-particulate areas



Product Attributes

Category Specifications
AC Output (On-Grid)
Max. Power (kVA) 33 kVA
Rated Power (kW) 30 kW
Voltage Configuration 480V High-Leg Delta with Split Phase
Voltage Range 384-552V
Rated Current (A) 37A
Frequency 50/60 Hz (±5 Hz adjustable)
THDi <3%
Power Factor Adjustable (0.8 leading/lagging)
AC Output (Off-Grid)
THDu <1% (linear), <5% (nonlinear)
Overload Capacity 110% continuous
PV Input
Max. PV Voltage 1,000V
Max. PV Power 36/72 kW
MPPT Trackers 1/2
MPPT Voltage Range 250-850V
Battery
Voltage Range 250-850V
Max. Charging Power 36/72 kW
Physical Data
Dimensions (W×D×H) 800×800×1,900 mm
Weight 620-650 kg
Operating Temperature -30°C to 55°C
Protection Rating IP20
Noise Level <70 dB
Communication RS485, CAN, TCP/IP

  •
